Benefits of polyurethane foam
Unique aluminium grease filters are enhanced with a special polyurethane foam that eliminates up to 98% of all grease particles and other impurities. At the same time, the hood maintains its absorption efficiency.
Shiny and fingerprint-free finish
All stainless steel surfaces are coated with a special TouchFree film that prevents fingerprint markings, leaving the surface always shiny and making cleaning much easier.
.png)
See what you're cooking
LED lighting provides excellent and highly efficient illumination of the cooking hob and represents an important aesthetic and functional element in the kitchen. Its useful life is thirty times as long as that of conventional light bulbs, and it saves up to ten times as much power.
Energy class
 C
Venting tube diameter
 15 cm
Colour of housing/chimney
 stainless steel
Lightning efficiency class
 A
Material of housing/chimney
 stainless steel and varnished metal
Fluid dynamic efficiency class
 B
Grease filtering efficiency class
 A
Maximum extraction rate by extraction operation
 647 m³/h
Maximum extraction rate by recirculation operation
 499 m³/h
Lamp type
 LED
Control setting
 Button control
Power of lights
 6 W
Number of lights
 2
Number of speed positions
 3
Air flow by extraction version, step 1
 250 m³/h
Air flow by extraction version, step 2
 433 m³/h
Air flow by extraction version, step 3
 647 m³/h
Height
 310 mm
EAN code
 3838942136900
Motor type
 Capacitor motor
Net weight
 14.2 kg
Gross weight
 16.2 kg
Product code
 565735
Connected load
 246 W
Filter material
 Washable aluminium with polyurethane foam
Max. noise level
 68 dB(A)re 1 pW
Number of motors
 1
Number of filters
 4
Dimensions (W×H×D)
 90 × 31 × 30.5 cm
No return airflow flap
 150 mm
Nominal current of fuse
 10 amp
Annual energy consumption
 66.4 kWh
Dimensions of packed product (W×H×D)
 100 × 37 × 37 cm
Coal filter code (optional as separate purchase)
 530121
